TGL Home Golf Simulator Bundle

TGL Golf Enclosure

Lay out all parts first and arrange the poles by size. Build the base frame using the corner units and joining poles, then lay the fabric over the frame with the Velcro straps at the rear and the plush side facing down. Feed the top centre poles through the fabric pockets, connect them to the upper side sections, then fit the front centre poles to complete the frame.

Fasten the Velcro around the front poles first, then the base and rear poles, pulling the fabric tight as you go. Attach the impact screen to the inner Velcro strips from one corner, using the longer bungee toggles across the top and the shorter toggles down the sides.

Full Swing KIT Launch Monitor

Charge the Full Swing KIT using the charging port on the left-hand side. A full charge takes around 5 hours. While charging, download the Full Swing app, create or log in to your account, pair the KIT with your device and connect it to Wi-Fi so updates can install. Keep the unit in charging mode during updates.

Once charged and updated, press and hold the Power button for 2 seconds. Extend the rear leg and place the KIT 10 feet directly behind the ball, level with the hitting area and free from obstructions. Start a practice session in the app, connect to the KIT, select your environment and club, then align the white line with your target. For Full Swing software, your PC or laptop must meet the minimum specification: Windows 10 64-bit, Intel Core i7, 16 GB RAM, NVIDIA GeForce RTX 4060 and 120 GB free storage.

Golf Hitting Mat

Carefully unbox the mat and place it on a clean, flat surface such as a patio, garage floor or simulator area. Roll it out and allow it to settle until flat and stable, then insert the three hitting sections and fit the rubber or plastic tees into the perforated holes before use.

TGL Golf Enclosure Specifications

TGL 1
• Outer Frame: 2.7m (w) x 2.6m (h) x 1.6m (d)
• Inner Frame: 2.6m (w) x 2.5m (h) x 1.5m (d)
• Screen: 2.4m (w) x 2.3m (h) / Ratio 1:1*

TGL 2
• Outer Frame: 3.1m (w) x 2.6m (h) x 1.6m (d)
• Inner Frame: 3.0m (w) x 2.5m (h) x 1.5m (d)
• Screen: 2.8m (w) x 2.3m (h) / Ratio 4:3*

TGL 3
• Outer Frame: 3.7m (w) x 2.6m (h) x 1.6m (d)
• Inner Frame: 3.6m (w) x 2.5m (h) x 1.5m (d)
• Screen: 3.4m (w) x 2.3m (h) / Ratio 4:3*

TGL 4
• Outer Frame: 4.1m (w) x 2.6m (h) x 1.6m (d)
• Inner Frame: 4.0m (w) x 2.5m (h) x 1.5m (d)
• Screen: 3.8m (w) x 2.3m (h) / Ratio 16:10*

TGL 5
• Outer Frame: 3.1m (w) x 3.1m (h) x 3.1m (d)
• Inner Frame: 3.0m (w) x 3.0m (h) x 3.0m (d)
• Screen: 2.8m (w) x 2.8m (h) / Ratio 1:1*

TGL 6
• Outer Frame: 4.0m (w) x 3.1m (h) x 3.1m (d)
• Inner Frame: 4.0m (w) x 3.0m (h) x 3.0m (d)
• Screen: 3.8m (w) x 2.8m (h) / Ratio 4:3*

Please leave at least 50cm behind and 20cm on either side of the enclosure as buffer space for ball impacts. All measurements are estimates.

Full Swing KIT Launch Monitor

Hardware & Tracking

• Radar Type: Patented 24GHz dual-mode, machine learning enhanced radar
• Camera: Full HD 1080p at 60fps with automatic swing video capture
• Display: 5.3” ultra-bright Full HD OLED display, 1920 x 1080, with 16.7 million colours
• Dimensions: 26cm x 16.7cm x 5.9cm (h x w x d), extending to 9.5cm deep with the support leg
• Weight: 1.8kg, or 2.6kg including carry bag and charger
• Processor: Dual-core A9

Data Points Tracked

• Ball Data: Carry Distance, Total Distance, Spin Rate, Spin Axis, Ball Speed, Apex Height, Side Carry and Side Total
• Club Data: Club Speed, Smash Factor, Club Path, Face Angle, Face-to-Path, Attack Angle and Horizontal Angle
• Unlocks: All 16 data points are included out of the box, with no additional subscription required

Connectivity & Power

• Wireless: Wi-Fi 802.11a/b/g/n/ac and Bluetooth 5.0
• Battery: Built-in lithium-ion 8000mAh battery
• Battery Life: Approximately 5 hours of continuous use
• Charging: USB-C

Setup & Space Requirements

• Outdoor Use: Place the unit exactly 10 feet behind the golf ball
• Indoor Use: Requires 8–10 feet of ball flight to the impact screen or net, plus 8–10 feet behind the ball
• Recommended Room Depth: Around 18–20 feet indoors to allow for the device, ball flight and golfer stance

Software & Compatibility

• Companion App: Full Swing app available on iOS and Android
• Simulation: Compatible with third-party software, including E6 Connect and GSPro
• Analytics: Includes FS Combine powered by Clippd, allowing golfers to hit to custom targets and receive a 0–200 Shot Quality score

Golf Hitting Mat Specifications

• Width: 1.5m / 4' 11"
• Height: 1.2m / 3' 11"
• Turf Thickness: 17mm / 0.66"
• Rubber Base: 12mm / 0.47"
• Total Thickness: 29mm / 1.13"
• Hitting Inserts: Separate fairway, rough and bunker inserts
• Tee Holes: 6 perforated holes, with 3 left-handed and 3 right-handed positions
• Included Accessories: Rubber and plastic tees
